Compliant with CAP437 standard specifications, suitable for helicopter landing platforms in various explosion mixed gas environments, such as offshore oil drilling platforms, various LNG ships, and the helicopter landing platform in petroleum and chemical smelting enterprises. Used to issue warning when there is a potential danger to the helicopter or personnel on board the platform, indicating that the helicopter deck is currently unable to land and is installed near the helicopter deck.
| Type | CXDJ-10FB |
|---|---|
| EX Mark | Ex db II C T6 Gb |
| Rated Voltage | AC100~240V 50/60Hz, DC24V |
| Power | Max. 60W |
| Flashing Frequency | 120 Flash / minute; 60 Flash / minute |
| Horizontal / Vertical Arc | 360° / ±3° |
| Luminous Intensity | 0~90°≥176cd; 2~10°≥700cd; 0~90°≥60cd; |
| Illuminant | LED |
| Illuminant Colour | Red |
| Protection Class | IP66 / IP67 |
| Installation | Base Mounting Type |
| Ambient Temperature | -40°C ~ +55°C |
| Material | Aluminium Alloy |
| Lampshade Material | Toughened Glass |
| Weight | 3.9kg |
| Certification | IECEx, ATEX & ABS |
